MV-CU200-20GM

Name: 20MP Area Scan Camera, GigE, AR2020, Mono
Brand: Hikrobot
SKU: MV-CU200-20GM

20MP Area Scan Camera, GigE, AR2020, Mono

Stok Kodu: ARMK-HIK-CAM-ASC-CU200-20GM

SensörAR2020

Çözünürlük19.7 MP· 19.7

Kare hızı5fps

ShutterRolling

ArayüzGigE· GigE Vision

Lens mountC

RenkMono

MuhafazaBox

MarkaHikrobot

✓ Stokta · stok ve teslim süresi için teklif alın.

Teknik Özellikler

Model

Performans

Elektriksel Özellikler

Veri Arayüzü: Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Dijital G/Ç: 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Güç Kaynağı: 9 VDC to 24 VDC; PoE is optional
Güç Tüketimi: Typ. 2.0 W @ 12 VDC

Mekanik

Lens Bağlantısı (Mount): C-mount
Boyut (lenssiz): 29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
Ağırlık: Approx. 100 g (0.2 lb.)
Koruma Sınıfı: IP30 (under proper lens installation and wiring)
Sıcaklık: Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Nem: 20% RH to 95% RH (no condensation)

Genel

İstemci Yazılımı: MVS or third-party software meeting with GigE Vision Protocol
İşletim Sistemi: 32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux
Uyumluluk: GigE Vision V2.0, GenICam
Sertifikasyon: CE, RoHS, KC
